1997 -2001 Honda CR250 - Service Specifications - Carburetor Specifications

97-01 Honda CR250 Keihn & Mikuni Carburetor Specifications

1997 -2001 Honda CR250 - Service Specifications - Carburetor Specifications

If you need parts and tools make sure to buy them here!

Carburetor Make And Identification Number

1997-1998Keihin PJ28L
1999Keihin PWK00A
2000Keihin PWK00B
2001Mikuni TMX 11A
Piston Type and Bore DiameterPiston valve; 38mm

Main Jet

1997-1998175
1999190
2000180
2001420

Slow Jet

1997-199855
199942
200048
200135
Power Jet (97/98 only)42

Jet Needle

1997-1998 R1369MS
1999 R1370DKA
2000 A715/289R/A327/A287
2001 6BEH1-73
Jet needle slip position3rd groove

Pilot Air Screw Turns Out

1997-19992
20001-1/2
20011-3/4

Bowl Float Height

1997-200016mm
200115mm
*Float measurement is above gasket surface for float bowl. The float should touch, but not compress the needle valve.
